Ciliates: Colpidium
Click on the above picture to open an album of Colpidium photomicrographs
Watson Bactil Microscope
Objective: Watson x30 parachromat
Wilska phase contrast: spot
Ocular: Olympus P15
Sample from Warnham Millpond: 28-March-2004
Image enhanced by use of Paint Shop Pro Artistic effects: Topography
Ciliates: Peniculina - Paramecium
Zeiss GFL Microscope
Objective:x20 Zeiss Plan achromatic
Ocular: Watson x8 compensating
Brightfield/Flash (2nd curtain)
Camera: Canon Powershot S50
F 4.9, ISO 50
Sample from Warnham millpond & kept 1 week
Camera: Canon Powershot S50
Paramecium has an interesting appearance in polarised light, as shown in these short videos (.avi files):
Paramecium video 1 (3.2 MB)
Paramecium video 2 (2.1 MB)
Paramecium bursaria
Microscope: Zeiss Standard GFL
Ocular: Zeiss Kpl 10/18
Objective: Leitz 40/0.7 NPL Fluotar ICT
Substage: Leitz ICT
Differential Interference Contrast
Flash
Sample from moss on side of garden pond 13 Oct 2007
Ciliates: Cyrtophores - Phascolodon (?)
Pictures presented are all of the same individual. I was unable to observe the cylinder of rods (nasse) that this organism possesses, so it could be Bursaria, which has a similar scoop-shaped form
Click on the above picture to open an album of Phascolodon photomicrographs
Microscope: Watson Bactil Binocular
Ocular: x8 Compensating
Objective: x30 para
Wilska Phase Contrast (spot)
Sample from Warnham Millpond, kept several weeks.
Camera: Canon Powershot S50
Drawing from Free-Living Freshwater Protozoa, A Colour Guide by D J Patterson, drawings by Stuart Hedley, ASM Press, 2003
Ciliates: Hypotrichs - Oxytricha
a fast swimming ciliate
Single organism
Conjugation of two Oxytricha
This exchanges genetic information between individuals
Division of Oxytricha to produce two individuals
All Oxytricha images:
Microscope: Zeiss Standard 16
Ocular: Zarf G9 Adapter
Objective: Leitz 25/0.55 ICT NPL Fluotar
Substage: Leitz ICT
Camera: Canon Powershot G9/Vivitar flash
Sample from garden pond, Feb 2008
Ciliates: Peritricha - Vorticella
A colony forming bell shaped protozoan that lives on contractile stalks. Although some of the specimens shown were not collected at Warnham, there were many to be found attached to plant fragments in samples I collected there in June/July 2003. Vorticella feeds by drawing food in currents created by beating cilia at the mouth of the "bell".
Unidentified peritrich
Objective: Watson x 10 parachromat
Ocular: Wild x 10 photo with extension/adapter
Rheinberg/COL illumination
Peritrich has non contractile branched stalks
On tail of Cyclops
Sample from Warnham, collected 28-Dec-2003, photo 17-Jan-2004
Opercularia
Objective: Zeiss x10/0.22 plan achromat
Ocular: Watson x8 compensating
Brightfield
Camera: Canon Powershot S50
ISO 50, F4.9, 1/250 sec
Objective: Zeiss x40/0.63 plan achromat
Ocular: Watson x8 compensating
Brightfield/Flash
Sample from garden pond 24 Dec 2005
Strobilidium
An oligotrich ciliate
Zeiss GFL Microscope
Objective: Zeiss x20 plan achromat
Ocular: Watson x8 compensating
Brightfield
Camera: Canon Powershot S50
Flash, ISO 50, F8.0
Astylozoon
Click on the above image to see a gallery of images of this free swimming peritrich ciliate.
For a .AVI video (~3MB) click here
Watson Bactil Binocular Microscope
Objective: Watson x30 parachromat
Ocular: Watson x8 compensating
Substage: Watson Universal No. 1 Condenser
Wilska Phase Contrast (spot)
Camera: Canon Powershot S50
F4.9, 1/640 sec
Ciliates: Heterotricha - Stentor
Stentor feeds in a similar way to Vorticella.
Microscope: Zeiss Standard GFL
Objective: Leitz 40/0.7 NPL Fluotar ICT
Ocular: Olympus P15
Substage: Leitz ICT
DIC
Camera: Canon Powershot S50
ISO200, F5, Flash
3 frames stitched
Sample from Warnham Millpond, 08-Oct-2006
Click on the above picture to open an album of Stentor photomicrographs
Click here for an AVI video of Stentor (~2.7 MB)
Ciliates: Lacrymaria
"Tears of a swan"
Click on the above picture to open an album of Lacrymaria photomicrographs
Ciliates: Litonotus
Microscope: Zeiss Standard GFL
Ocular: Zeiss KPL W10/18
Objective: Leitz 25/0.5 NPL Fluotar ICT
Substage: Leitz ICT
(DIC)
Sample from Warnham Mill Pond (main pond)
18 Nov 2007
Ciliates: Suctoria - Tokophrya
Olympus FH microscope
Objective: Watson x40 with phase contrast mod
Ocular: Olympus P15
Sample taken from garden pond
Kariorelictida: Loxodes
Zeiss Standard GFL Microscope
Objective: Zeiss x40 PH2
Phase Contrast
Ocular: Watson x8 Compensating
Camera: Canon Powershot S50
ISO50, F4.9, Flash
Sample from garden pond mud
09 Oct 2005
Spirostomum
- often found with Loxodes
Watson Bactil Binocular Microscope
Objective: Watson x10 parachromat
Ocular: Watson x8 compensating
Darkground with substage stop
Camera: Canon Powershot S50
Sample from garden pond
Zeis GFL microscope
Objective: Zeiss x25 plan achromat
Ocular: Watson x8 compensating
Brightfield Illumination: 24000 mcd LED
Camera: Canon Powershot S50
ISO100, F4.9, 1/1000sec
Zeiss Standard GFL Microscope
Objective: Zeiss x40 PH2
Phase Contrast
Ocular: Watson x8 Compensating
Camera: Canon Powershot S50
ISO50, F4.9, Flash
Sample from garden pond mud
09 Oct 2005
Prostomes: Coleps
Ciliates with an apical mouth
Zeiss GFL Microscope
Objective: Ross 1/4 inch
Ocular: Watson x8 Compensating
Brightfield
Camera: Canon Powershot S50
ISO50, 1/1250 sec, F8
Olympus FH microscope
Objective: Gillett & Sibert x40 PH
Ocular: Watson x8 compensating
Phase contrast
Camera: Canon Powershot S50
ISO 50, F4.9, 1/60 sec
sample from garden pond
Cyclidiidae: Cyclidium
Zeiss GFL Microscope
Ocular: Watson x8 compensating
Objective: Zeiss x40 Ph2
Phase contrast
Sample from Warnham Millpond DP2, 10 July 2005
Camera: Canon Powershot S50
ISO200, F4.9, Flash
Lembadionidae: Lembadion
Zeiss GFL Microscope
Objective: Zeiss x40 PH2 brightfield
Ocular: Watson x8 Compensating
Camera: Canon Powershot S50
ISO 50, F4.9, Flash
Sample from jar of pondwater kept several weeks on windowsill, Oct 2005
